VACOTEK VWM44 4K Samless HDMI Matrix 4x4 with Video Wall

Technical

HDMI Compliance

HDMI 2.0

HDCP Compliance

HDCP 2.2

Video Bandwidth

18Gbps

Video Resolution

480i ~1080P@50/60Hz, 4K2K@24/30Hz, 4K2K@60Hz

Color Space

RGB, YCbCr 4:4:4, YCbCr 4:2:2, YCbCr 4:2:0

Color Depth

8/10/12-bit

Audio Formats

LPCM, Dolby Digital/Plus/EX, Dolby True HD, DTS, DTS-EX, DTS-96/24, DTS High Res, DTS-HD Master Audio

ESD Protection

IEC 61000-4-2:

±8kV (Air-gap discharge) , ±4kV (Contact discharge)

Connection

Input ports

4 × HDMI INPUT [Type A, 19-pin female]

4 × L/R AUDIO INPUT [3.81mm, 3pin Phoenix Connector]

Output ports

4 × HDMI OUTPUT [Type A, 19-pin female]

4 × OPTICAL AUDIO OUT [S/PDIF]

4 × L/R AUDIO OUT [3.81mm, 5pin Phoenix Connector]

Control ports

1 × TCP/IP [RJ45]

1 × RS-232 [D-Sub 9]

1 × IR EXT [3.5mm, Stereo Mini-jack]

4 × IR INPUT [3.5mm, Stereo Mini-jack]

4 × IR OUTPUT [3.5mm, Stereo Mini-jack]

Mechanical

Housing

Metal Enclosure

Color

Black

Dimensions

440mm [W] × 203mm [D] × 44.5mm [H]

Weight

5Kg

Power Supply

AC 110 - 240V

Power Consumption

60W (Max)

Operating Temperature

32 - 104°F / 0 - 40°C

Storage Temperature

-4 - 140°F / -20 - 60°C

Relative Humidity

20%~90% RH (non-condensing)
